10 mm Edge-Lit LED Panel Light Manufacturer for Commercial Projects
ShineLong's 10 mm edge-lit panel range includes EU/AU and US ceiling formats. Compare the model, driver arrangement and photometric data, then send your project brief for OEM/ODM review or a quotation.
- 10 mm Slim Body
- Edge-Lit PMMA Optics
- EU/AU & US Models
- OEM/ODM Support
10 mm Edge-Lit Panels for Commercial Ceilings
A 10 mm panel body helps keep the visible fixture shallow. Select the actual grid size, input-voltage version and driver arrangement before you approve the ceiling schedule.
ShineLong supplies the Slice series for offices, education, retail and other indoor commercial projects. The panel uses aluminum and PMMA construction; its driver and installation accessories need their own clearance in the ceiling design.
10 mm Edge-Lit Panel Design and Market Documents
A slim aluminum frame and PMMA optical assembly are listed for the series. Check the selected model and control package against the current market sheet.
10 mm Panel Body
Use the actual face dimensions and ceiling opening on the model drawing when specifying the fixture.
Edge-Lit PMMA Optics
The light-guide construction is designed for an even illuminated face; evaluate glare using the selected photometric file.
Aluminum Frame
The slim frame supports recessed, surface or suspended installation with the corresponding hardware.
Mounting Options
Review the recessed, suspended and surface installation drawings and confirm the hardware supplied with the selected article.
The current sheets list IP40 and IK06. Confirm suitability for the room conditions.
Documentation by Destination Market
Request the certificate or listing record for the exact article number and driver supplied with your order.
Compare Panel Models, Light Distribution and Packing
Select the destination market to see its fixture sizes, electrical values and optical data. US grid names in feet are nominal; millimetre dimensions are the actual fixture measurements.
Model Selection
| Article number | Fixture size | Power | Lumen output |
|---|---|---|---|
| SL-P1112-X-18B | 295 × 295 × 10 mm | 12 W | 1,200 lm |
| SL-P2240-X-18B | 595 × 595 × 10 mm | 40 W | 4,400 lm |
| SL-P2240-X-18B2 | 620 × 620 × 10 mm | 40 W | 4,400 lm |
| SL-P1440-X-18B | 1195 × 295 × 10 mm | 40 W | 4,400 lm |
| SL-P2450-X-18B | 1195 × 595 × 10 mm | 50 W | 5,500 lm |
| SL-P2460-X-18B | 1195 × 595 × 10 mm | 60 W | 6,600 lm |
X identifies the CCT in EU/AU article numbers; confirm the full order code on the pro forma invoice.
General Specifications
- Light source
- SMD2835
- CRI
- Ra >80
- Beam angle
- 120° nominal
- CCT
- 3000 / 4000 / 5000 / 6000 K
- AC input
- 200–240 V · 50/60 Hz
- DC output
- 30–40 V
- SDCM
- <4
- Power factor
- >0.95
- Operating temperature
- −20 to +40 °C
Optical Performance Options
| Optical version | Datasheet efficacy |
|---|---|
| Standard frosted | 110 lm/W |
| Premium frosted | 130 lm/W |
- Efficacy is based on 4000 K at 25 °C ambient.
- Efficacy and wattage tolerances are ±10%.
- UGR <19 can reduce efficacy by 5–8%; CRI >90 can reduce it by 10–15%.
- Confirm the chosen optic and driver in the final submittal.
Luminous Intensity Distribution
Representative distribution from the EU/AU specification sheet.
Request Sample IES FileMeasured sample: SL-P2240-W-18B, 40 W, 4000 K. Use the IES file for the ordered configuration in final calculations.
EU/AU Carton & Container Data
Each EU/AU carton holds five panels; container quantities are fixture counts.
| Fixture size | Carton size | Units/carton | Carton N.W. | Carton G.W. | 20′GP / 40′GP / 40′HQ |
|---|---|---|---|---|---|
| 295 × 295 × 10 mm | 350 × 195 × 350 mm | 5 pcs | 5.5 kg | 7.5 kg | 5,220 / 10,800 / 12,220 (pcs) |
| 595 × 595 × 10 mm | 650 × 195 × 650 mm | 5 pcs | 16 kg | 20 kg | 1,485 / 2,970 / 3,600 (pcs) |
| 620 × 620 × 10 mm | 670 × 195 × 670 mm | 5 pcs | 17 kg | 21 kg | 1,305 / 2,700 / 2,925 (pcs) |
| 1195 × 295 × 10 mm | 1250 × 195 × 355 mm | 5 pcs | 16 kg | 20 kg | 1,200 / 2,700 / 3,300 (pcs) |
| 1195 × 595 × 10 mm | 1250 × 195 × 655 mm | 5 pcs | 35 kg | 40 kg | 660 / 1,485 / 1,800 (pcs) |
Model Selection
| Article number | Fixture size | Power | Lumen output |
|---|---|---|---|
| SL-P2230-X-18B | 602 × 602 × 10 mm(2 × 2 ft) | 30 W | 3,300 lm |
| SL-P2240-X-18B | 602 × 602 × 10 mm(2 × 2 ft) | 40 W | 4,400 lm |
| SL-P2450-X-18B | 602 × 1211 × 10 mm(2 × 4 ft) | 50 W | 5,500 lm |
| SL-P1440-X-18B | 302 × 1211 × 10 mm(1 × 4 ft) | 40 W | 4,400 lm |
| SL-P2460-X-18B | 602 × 1211 × 10 mm(2 × 4 ft) | 60 W | 6,600 lm |
X identifies the CCT in US article numbers; specify the required color temperature in the purchase brief.
General Specifications
- Light source
- SMD2835
- CRI
- Ra >80
- Beam angle
- 120° nominal
- CCT
- 3000 / 4000 / 5000 / 6000 K
- AC input
- 100–277 V · 50/60 Hz
- DC output
- 30–40 V
- SDCM
- <4
- Power factor
- >0.95
- Operating temperature
- −20 to +40 °C
Optical Performance Options
| Optical version | Datasheet efficacy |
|---|---|
| Standard frosted | 110 lm/W |
| Premium frosted | 130 lm/W |
- Efficacy is based on 4000 K at 25 °C ambient.
- Efficacy and wattage tolerances are ±10%.
- UGR <19 can reduce efficacy by 5–8%; CRI >90 can reduce it by 10–15%.
- Confirm the chosen optic and driver in the final submittal.
Luminous Intensity Distribution
Representative distribution from the US specification sheet.
Request US Model IES FileSend the US article number, output version and CCT for its matching IES file.
US Carton & Container Data
Each US carton holds four panels; container quantities are fixture counts.
| Fixture size | Carton size | Units/carton | Carton N.W. | Carton G.W. | 20′GP / 40′GP / 40′HQ fixtures |
|---|---|---|---|---|---|
| 602 × 602 × 10 mm(2 × 2 ft) | 680 × 300 × 740 mm(26.77 × 11.81 × 29.13 in) | 4 pcs | 14 kg(30.86 lb) | 18 kg(39.68 lb) | 684 / 1,440 / 1,536 (pcs) |
| 302 × 1211 × 10 mm(1 × 4 ft) | 1300 × 300 × 440 mm(51.18 × 11.81 × 17.32 in) | 4 pcs | 14 kg(30.86 lb) | 18 kg(39.68 lb) | 560 / 1,260 / 1,512 (pcs) |
| 602 × 1211 × 10 mm(2 × 4 ft) | 1300 × 300 × 740 mm(51.18 × 11.81 × 29.13 in) | 4 pcs | 28 kg(61.73 lb) | 35 kg(77.16 lb) | 336 / 756 / 896 (pcs) |
Container loads are datasheet figures; confirm the final SKU mix and pallet plan before freight booking. Request the current gross weight for the 295 × 295 mm EU/AU carton with your shipping quotation.
EU/AU and US Driver Arrangements
The two market sheets show different power arrangements. Allow for the specified driver and its service clearance when preparing the ceiling detail.
External Driver + Panel
The driver is a separate unit connected to the panel. Confirm driver location, access and the ordered standard or dimming version.
Power Assembly on the Fixture
The US wiring drawing shows the power and wiring enclosure attached to the panel body. Check rear clearance and connection access for the selected version.
Panel Installation and Wiring
Check the ceiling opening, driver position, power isolation and the accessories supplied for the selected mounting method.
Match the Wiring
Use the driver diagram that belongs to the ordered control version.
Measure the Opening
Work from the actual model dimensions rather than a nominal grid label.
Check the Hardware
Confirm whether the order includes a frame or suspension kit beyond the recessed standard.
Commercial Ceiling Applications
The datasheets name offices, hospitals, universities, schools, supermarkets, showrooms and exhibition halls. The lighting plan and local requirements decide the final fit.
Office & Meeting Rooms
Review screen reflections, task illuminance and lighting controls.
Meeting-room guidance →Education
Assess desk and teaching-wall light levels with the chosen IES file.
Retail
Plan general ceiling illumination separately from accent and display lighting.
Store-lighting guidance →Healthcare Support Areas
Check hygiene, electrical and emergency-lighting rules for the actual room.
Customize a Panel Light Around Your Project Brief
Choose from the current panel platform or share a new specification. ShineLong reviews the optical, electrical, mechanical and branding requirements before confirming the production route.
Build to Your Specification
Send your drawing, market requirements and target performance. Engineering reviews the design, sample and tests needed for production.
Adapt a Current Panel Platform
Start with an existing format and define the changes needed for your brand, installation or project specification.
Choose the Color Temperature
The current market sheets list 3000 K, 4000 K, 5000 K and 6000 K. Specify the CCT in your order brief and confirm the approved sample before production.
For other color targets, send the required specification for engineering review.
Match the Format and Installation Fit
Select a current EU/AU or US panel format from the model table, then send your ceiling opening or project drawing. Nonstandard sizes require a separate feasibility, tooling and sample review.
Compare current sizes →Select the Installation Fittings
Send the ceiling type and desired installation method. The corresponding clips, suspension set or surface frame can be reviewed with the selected article number and packing plan.
Hardware contents are confirmed in the order specification.
Discuss the Frame Appearance
Share your preferred finish, color reference and project quantity. The factory can review material treatment, sample appearance and order feasibility for the chosen panel format.
A visual sample and written specification are required before a custom finish is approved.
Review the Optical Surface
Send your UGR target, room use and lighting layout. The selected optical solution should be checked with a physical sample, measured output and its own IES file.
The current sheets note an efficacy trade-off for a UGR <19 configuration.
Specify Controls, Emergency and Driver
State the destination market, dimming protocol and emergency requirement. The selected function needs its own wiring plan and sample approval.
The available wiring arrangements differ by market and ordered version.
Define the Driver Specification
Send any approved component list, electrical target or brand preference with the market and control brief. Engineering checks fit, performance and certification scope before a driver is quoted.
Compare the market-specific driver positions →
Add Your Brand to the Shipment
Submit logo files, label content, carton artwork and destination-market rules. Packaging and print proofs are reviewed with the selected SKU, quantity and shipping method.
The carton graphic is illustrative; final artwork follows your approved files.
Destination market, target article or drawing, CCT, output, controls, mounting, quantity, branding files and delivery location.
Learn about ShineLong's OEM/ODM and engineering service process.
Project Specification Checklist
Confirm the ceiling opening, market voltage, driver location and mounting kit against one article number. Add the chosen photometric file and current packaging plan to the submittal.
For layout decisions, see the flat-panel selection guide. A completed technical brief helps the factory team check supply and documentation before quoting.
LED Panel Light Videos
Watch panel light production, a US production flow, a custom-size panel example and a mounting animation.
Need footage of your selected panel configuration?
Request a Product VideoLED Panel Light Questions Before You Specify or Order
What edge-lit panel sizes fit EU/AU and US ceiling grids?
The available fixture dimensions differ by market. The US range uses nominal 1 × 4 ft, 2 × 2 ft and 2 × 4 ft grid names; check the actual millimetre size in the US model table. EU/AU has its own metric formats. Send the ceiling opening if the fit is critical.
Is the LED driver external or mounted on the panel?
The current EU/AU drawing shows a separate external driver connected to the panel. The US drawing shows the power and wiring enclosure attached to the fixture body. Check rear clearance and service access for the version you order.
Can I order dimming or emergency functions?
The EU/AU sheet illustrates standard, 0/1–10 V, DALI and emergency arrangements. The US sheet illustrates standard, 0/1–10 V and emergency arrangements. Specify the market and control protocol so the supplied driver and wiring can be confirmed.
Can I download an IES file for lighting calculations?
A measured EU/AU 40 W, 4000 K sample file is available below the photometric diagram. For a final lighting layout, request the IES file matching the ordered size, optic, output version and CCT; a sample from another configuration should not be used as its substitute.
Which certifications apply to an EU/AU or US order?
The EU/AU datasheet lists TÜV-GS, SAA, CE and RoHS; the US datasheet lists UL/cUL, DLC Premium and RoHS. Ask for the certificate or listing record covering the exact article number and driver in your quotation.
Can ShineLong customize the panel for an OEM or ODM order?
ShineLong can review CCT, format, controls, installation hardware, label and carton requirements. Frame finish, glare-control optics and driver preferences need feasibility, sample and document checks before they are confirmed for a particular order.
Can this panel light be installed in a damp or washdown area?
The current panel sheets list IP40. Share the cleaning and moisture conditions before specifying it; an exposed damp or washdown location may require a different rated luminaire.
What information do you need to quote a panel light project?
Send the destination market, ceiling opening or layout, target output and CCT, control needs, documentation requirements, quantity, branding files and delivery location. This lets the team check the correct panel and current packing plan.
Ready to Price Your Panel Light Project?
Send your model shortlist, destination market, quantity, ceiling drawing and OEM/ODM requirements. ShineLong will review the configuration and current packing plan for your enquiry.
