K-lens Dali Control
LED Linear Light
LED Linear Lights
- IP40 Waterproof, IK09 Protection
- Instant seamless connection
- Beam Angle: 45°/90°,Beam angle optional
- Aluminum housing+Asymmetric & Symmetric lens+S304 clips
- SMD2835 LED Light Source with Global Patent Protection
- Flicker Free Internal Driver
- High Efficacy, 130 lumens per watt (+/-5%)
- L80B10 lifespace of 50,000 Hours (@ Ta = 25°C)
- 5 Years Warranty
K-lens DALI control linear lights through its advanced DALI dimming feature. DALI (Digital Address Lighting Interface) is an international standard intelligent control protocol that enables individual addressing of each fixture for individual dimming, group control and multi-scene presets. The system supports stepless dimming, smooth dimming curve and no strobe. At the same time, the DALI system has a two-way communication function, real-time monitoring of the status of the lamps and lanterns and fault detection or energy management. K-lens DALI control LED lights not only can achieve high energy efficiency, but also through the intelligent regulation for users to create a comfortable, personalized lighting environment, very suitable for the intelligent needs of commercial and office space.
Date Sheet
| Article Number | Power (W) | Lumen (lm) | Working Current (mA) |
| SL-A40X2-20-XL | 20 | 2800 | 450 |
| SL-A40X4-36-XL | 36 | 5040 | 950 |
| SL-A40X5-45-XL | 45 | 6300 | 1200 |
* Where the first “X” represents diffuser type, it can be T(Transparent)
The second “X” represents CCT, it can be W(3000K/4000K), P(5000K), C(6000K)
| Light Source | SMD2835 |
| CRI | >80 |
| Beam Angle | 45°/90° |
| CCT | 3000K/4000K/5000K/6000K |
| AC Input | 200-240V 50/60Hz |
| DC Output | 30-40V |
| SDCM | <4 |
| Waterproof | IP40 |
| IK Rate | IK09 |
| Power Factor | >0.95 |
| Warranty | 5 Years |
| Operating Temperature | -20~+40℃ |
K-lens Dali control LED Linear Light Efficacy Version
Cover Standard
Transparent 140lm/w
Please note:
1. Above efficacy based on 4000K
2. All values are based on an ambient temperature of 25°C
3. Efficacy tolerance is ±10% and wattage tolerance is ±10%
4. lf CRl> 90, light efficiency will be reduced by 10-15%
K-lens Details
