Disc Round Panel Light
Style Your Home or Office the ShineLong Way
Get the 2019 New Price Today!
Disc Round Panel Light
Product detail
- CE, RoHS certified
- IP40
- 5 Years Warranty
- Non-dimming, triac dimming, 0~10v dimming, cct dimming, DALI version available
Disc Round Panel Light Features
Thickness
Ultra-thin 14mm
Material
AL + PMMA
Driver
TUV/ENEC listed driver, flicker free
Instant On/Off
no noise/UV/light leak/shadow
SMD 2835
Global patent protection led source, projected lifespan>100,000hrs
Lifespan
Minimal lifespan 50, 000hrs
Temperature
Operating: -20 ~ +50°C
Application
Office, University/School, Show room, Hospital, Exhibition Hall, Supermarket
Disc Round Panel Light Desription
With LED lighting panels gaining traction worldwide, most people are used to the square and rectangular version of these amazing fixtures. But, what happens when you want an LED panels and the square or rectangular ones don’t quite fit into your styling requirements? Well, you should consider using our round panel light fixtures. Yes, ShineLong also manufactures Disc LED panels that equally strong, durable, and aesthetically appealing.
In fact, these light fixtures come with extra benefits. So, why should you buy our Disc Panels?
Well, these awesome LED light fixtures are highly applicable and can be used domestically and commercially. Therefore, if you’ve been searching for the best-LED lights for your home’s bathroom, kitchen, living rooms, corridors, bedrooms, porch, home office, dining area, study, and commercial spaces like offices, supermarkets, or showrooms, the ShineLong Disc LED is exactly what you need.
That’s because aside from it having a charming round shape, this fixture also comes in different colors, sizes, and wattages. This gives you more options to choose from in order to create the perfect décor and atmosphere in the intended room.
What’s more, these round panel light fixtures are light-weight, ultra-thin, and very convenient due to their flicker-free, noiseless, no UV, no shadow, no leak nature. They operate at an efficiency of 80~90lm/W and can last for over 50,000 hours. Moreover, ShineLong Disc Panel LEDs are eco-friendly and certified by CE and RoHS. They are made from a high-quality PMMA diffuser and a #6063 Aluminum frame. They also have to dim support options that include 0~10V, TRIAC, CCT, and DALI. These fixtures have numerous other perks. If you’d like to place an order or to learn more about these awesome LED fixtures, feel free to contact us right now. It’s absolutely FREE and we always respond promptly.
Disc Round Panel Light Data Sheet
Article Number | SL-D12005-X | SL-D18010-X | SL-D24015-X | SL-D30020-X |
|---|---|---|---|---|
Size | Ø120 mm | Ø180 mm | Ø240 mm | Ø300 mm |
Power | 5 W | 10 W | 15 W | 20 W |
LEDs | 24 | 60 | 84 | 108 |
Beam Angle | 120 | 120 | 120 | 120 |
CRI | > 80 | > 80 | > 80 | > 80 |
AC Input | 200~240 V / 100~277 V | 200~240 V / 100~277 V | 200~240 V / 100~277 V | 200~240 V / 100~277 V |
DC Output | 30~40 V | 30~40 V | 30~40 V | 30~40 V |
SDCM | < 4 | < 4 | < 4 | < 4 |
Efficiency(±5%) | 60~70 lm/w | 80~90 lm/w | 80~90 lm/w | 90~100 lm/w |
Lumen Output | 300～350 lm | 800~900 lm | 1100~1300 lm | 1700~1900 lm |
Packing info | 10 pcs/ctn | 10 pcs/ctn | 10 pcs/ctn | 5 pcs/ctn |
Carton Size | 475x270x270 mm | 475x270x270 mm | 555x315x270 mm | 395x350x400 mm |
N.W.(kg)/CTN | 2.1 | 4.1 | 5.6 | 6.8 |
G.W.(kg)/CTN | 4.5 | 6.5 | 9.0 | 11.0 |
ASK FOR FREE
We are preparing the price, E-catalog, specification, IES file, test report, and DIALUX, please contact us for FREE.
